Processor
|
| |
100/83.3/75/66 MHz F.S.B
Intel Pentium Processor: P55C/P54C/P54CS 90MHz~233MHz
Cryix M II: 300MHz ~ 333MHz ,
6x86MX: PR166+ ~ PR266+MHz
AMD-K6®-2, AMD-K6® 233MHz ~ 350MHz
|
|
|
Chipset
|
| |
ALi® M1541 Aladdin V AGPset supports up to 100MHz F.S.B.
ALi® M1543 Super I/O Controller
|
|
|
Bus Architecture
|
| |
32-bit AGP Bus, 32-bit PCI Bus and 16-bit ISA Bus Compatible
|
|
|
Expansion Slots
|
| |
1 x 32-bit AGP Slot
5 x 32-bit PCI Slots
2 x 16-bit ISA Slots
|
|
|
Cache
|
| |
On Board Pipelined Burst SRAM 512KB (-5ns)
|
|
|
System Memory
|
| |
3 x 168-pin DIMM Sockets Support 8-384MB SDRAM/EDO
Features ECC/Parity Support (66MHz Only)
PC100 (100MHz)Compliant SDRAM Interface
|
|
|
AGP Connector
|
| |
AGP 1.0 Compliance Interface Supports both 1x and 2x Speed Mode with
Sidehand Address Capability
|
|
|
Onboard I/O
|
| |
2 x USB Ports onboard
1 x Floppy Port (Up to 2.88MB, 3 Mode)
2 x Serial Ports
1 x Parallel Port (EPP, ECP Port)
FIR TX/RX Header
|
|
|
Onboard PCI IDE
|
| |
2 x PCI Bus Master IDE ports (Support up to 4 IDE devices)
Support:
PIO Mode 3 & 4 : 17MB/Sec. DMD Mode 2 : 17MB/Sec. (Max.; The Actual
Transfer Speed Depends On HD)
ATAPI IDE CD-ROM and LS-120 Supported
Ultra DMA/33 : 33MB/Sec.(Synchronous DMA Mode)
|
|
|
Onboard PCI Audio
|
| |
High Performance ESS Solo-1™ PCI Audio Controller
Sound Blaster 16 and Microsoft Sound System Compatible
Up to 16-bit Stereo 44KHz Sampling Rate, Full Duplex
Microsoft® PC97/PC98 Compliant
Software WaveTable Bundled
3D Audio Effects and ESFMTM Music Synthesizer
|
|
|
OS Certification
|
| |
Microsoft PC97 Logo (Design for Windows95, Windows98 and WindowsNT)
Novell Yes Test Approved
Solaris H/W x86 Certified
NSTL Year 2000 Test Approved
|
|
|
CD-ROM Content
|
| |
Auto Run Software Install Utility
ALi® Bus Master IDE Driver
Intel® LDCM Hardware Monitoring, DMI Browser and Remote Access Utility
ESS® Audio Driver with S/W Wave Table Utility
ASUS PC Probe Hardware Monitoring Utility for Single Desktop User
|
|
|
BIOS
|
| |
2M-bit Flash EEPROM
Award® AGP BIOS
with ACPI, DMI, Green, Plug and Play Features
Enhanced ACPI Features for PC98/Win98
|
|
|
Other Features
|
| |
PC Health Monitoring ASIC Supports CPU Voltage, Fan Status, and System Temperature Detection
Intel® LANDesk Client Manager S/W and ASUS PC Probe Utility Bundled
|
|
|
Dimensions
|
| |
ATX Form Factor (8.3" x 12")
|
|
